SMD PTC Thermistors, Inrush Current Limiter

SMD PTC Thermistors, Inrush Current Limiter

Download Datasheet

Product Details

Features

Standard 240 J and high energy 340 J available
High number of inrush-power cycles: > 100 000 cycles
Suitable for reflow soldering
Can handle high direct voltage up to 1200 V
Highly resistant against shock and vibration
Insulated housing up to 3 kVAC
Self protecting in case of overload with no risk of over-heating
AEC-Q200 qualified

Applications

Inrush current limiting and energy-dump resistor in:
AC/DC and DC/DC converters
Energy dump and DC-Link circuits
Emergency discharge circuits
OBC, battery charging equipment
Motor drives
PTCES thermistors have resistance values that can change instantly based on the applied voltage levels and varying body temperatures.
